Medium Frequency Furnace Automatic Loader is automated equipment used together with medium frequency induction furnaces. It is mainly used for the **automatic conveying and charging of billets, round steel or scrap steel**, significantly reducing manual handling and improving production efficiency.

Today let's talk about the key points for selecting a medium frequency furnace automatic loader.
I. Distinguish the Process Type
- Billet through-heating: choose stepped pusher plate / pressure wheel / chain loading; clarify the billet diameter, length and single-piece weight.
- Metal melting charging: choose a vibrating charging car or screw feeder.
II. Capacity and Cycle Rate
Based on the hourly output of the medium frequency furnace, reserve 1.2–1.5 times the margin in loading capacity; the feeding speed should be variable-frequency adjustable and linked with the heating cycle.
III. Drive Type
- Small and medium billets: pneumatic drive, low cost;
- Heavy and large-spec materials: hydraulic drive is preferred, with greater thrust and stable operation.
IV. Anti-Jamming Design
1. Wear-resistant treatment for the stepped pusher plate; provide anti-stacking and anti-jamming detection, with alarm and shutdown on jamming.
2. Magazine capacity, and whether a skip-tipping function is needed.
3. For bent and deformed blanks, confirm that a larger bending allowance is acceptable.
V. Control and Linkage
1. PLC touch screen, storing multiple product recipes;
2. Can interface with the medium frequency furnace signals: material shortage alarm, feed-in-position signal;
3. Emergency stop and overload protection; electrical control enclosure protection class IP54 or above for high-temperature and dusty environments.
VI. Site Conditions
Three-phase 380V power supply; equipment placement space; furnace opening center height — the feeding center height must be aligned with the heating center of the medium frequency furnace.
VII. Commercial Terms and Acceptance
1. Clarify the consumable parts list: wear-resistant pusher plate, pressure wheel, chain, seals;
2. Acceptance indicators: feeding cycle rate, jamming failure rate, feeding centering; conduct on-site sample testing with blanks;
3. Damage caused by material jamming or blank deformation is generally not covered by the warranty.
